P350 Amplifier
P350 AMPLIFIER
In stock
Phase Technology 13.25" x 17.25" High Current 350-Watt Amplifier
Phase Technology 13.25" x 17.25" High Current 350-Watt Amplifier
The P350 is the companion amplifier to Phase Technology custom in-wall subwoofer systems but its use is not limited to only subwoofer applications. It also has the flexibility of operation as a full range high current, high performance, mono-block audio power amplifier. The P350 is designed to be used with SoundTube, SolidDrive, Rockustics, and Phase Technology. When using with outdoor products, the amp should be located indoors or in a weather-proof encasing.
Owner's Manual | CE Certification
About PhaseTechColor | Black |
---|---|
UPC | 748252173577 |
Manufacturer | Phase Technology |
Manufacturer's Category | Amplifier |
Depth | 13.25 in / 336.55 mm |
Height | 2 in / 50.8 mm |
Width/Diameter | 17.25 in / 438.15 mm |
Shipping Weight | 23.9 lbs / 10.84 kg |
Carton Height | 7 in / 177.8 mm |
Carton Length | 21.5 in / 546.1 mm |
Carton Width | 16.75 in / 425.45 mm |
Included Accessories | Rack Mount Adapters |
Input Impedance | 22K Ω Unbalanced, 37.5K Ω Balanced |
Output Type | Gold Plated Terminals #10 AWG Max, Banana Plug |
Output Power | 350 Watts RMS >.5% THD @ 4 Ohms, 700 Watts peak | 225 Watts RMS >.5% THD @ 8 Ohms, 400 Watts peak |
Power Requirements | 120v: 3 Amps @ 8 Ω; 120v: 5.5 Amps @ 4 Ω |
Voltage Gain | 33 dB |
Crossover Frequency | 40 - 120 Hz; 24 dB /octave |
Frequency Response (+0/.25 dB) | 10 Hz - 20 kHz |
Frequency Response (± 3 dB) | 5 Hz - 60 kHz |
