P350 Amplifier

P350 AMPLIFIER
Find a Reseller
In stock
Phase Technology 13.25" x 17.25" High Current 350-Watt Amplifier

Phase Technology 13.25" x 17.25" High Current 350-Watt Amplifier

The P350 is the companion amplifier to Phase Technology custom in-wall subwoofer systems but its use is not limited to only subwoofer applications. It also has the flexibility of operation as a full range high current, high performance, mono-block audio power amplifier. The P350 is designed to be used with SoundTube, SolidDrive, Rockustics, and Phase Technology. When using with outdoor products, the amp should be located indoors or in a weather-proof encasing.

Owner's Manual | CE Certification

About PhaseTech
More Information
ColorBlack
UPC748252173577
ManufacturerPhase Technology
Manufacturer's CategoryAmplifier
Depth13.25 in / 336.55 mm
Height2 in / 50.8 mm
Width/Diameter17.25 in / 438.15 mm
Shipping Weight23.9 lbs / 10.84 kg
Carton Height7 in / 177.8 mm
Carton Length21.5 in / 546.1 mm
Carton Width16.75 in / 425.45 mm
Included AccessoriesRack Mount Adapters
Input Impedance22K Ω Unbalanced, 37.5K Ω Balanced
Output TypeGold Plated Terminals #10 AWG Max, Banana Plug
Output Power350 Watts RMS >.5% THD @ 4 Ohms, 700 Watts peak | 225 Watts RMS >.5% THD @ 8 Ohms, 400 Watts peak
Power Requirements120v: 3 Amps @ 8 Ω; 120v: 5.5 Amps @ 4 Ω
Voltage Gain33 dB
Crossover Frequency40 - 120 Hz; 24 dB /octave
Frequency Response (+0/.25 dB)10 Hz - 20 kHz
Frequency Response (± 3 dB)5 Hz - 60 kHz
