PhaseTech 3-way In-Wall Speaker

PhaseTech CI120 In-Wall Speaker

3-Way In-Wall Speaker with Extruded Aluminum Positive Clamping System. Versatile, high-performance in-wall speaker that can be used to compliment an upper-end home system. The CI120 uses the same woofers and midrange/tweeter assemblies as the Premier Collection series. The tweeter and midrange assembly absorb the horizontal sound waves through Unicell Acoustic treatment to minimize interaction with the mounting wall resulting in amazingly precise imaging and clarity. Additionally, the CI120 employs Phase Tech's patented Positive Clamping System, ensuring accurate control of low end performance and a clear reproduction of the sound into the listening space. 3.75 inch mounting depth allows this speaker to be mounted in shared walls. The CI120 pairs with Premier Collection's PC3.5 and PC9.5.

Owner's Manual

About PhaseTech
More Information
ManufacturerPhase Technology
Manufacturer's CategoryCI Custom Install Series
Depth3.9 in / 99.1 mm
Height19.25 in / 488.9 mm
Width/Diameter14.25 in / 361.9 mm
Shipping Weight27.8 lbs / 12.61 kg
Carton Height9 in / 228.6 mm
Carton Length28 in / 711.2 mm
Carton Width18.5 in / 469.9 mm
CertificationsCCC, CE, RoHS
Included AccessoriesGrille, Hole Template, Mounting Assembly
Optional AccessoriesRough-In Bracket (RB24 or RB-535)
Source InputsTerminal Strip
Cutout Depth3.75 in / 95.3 mm
Cutout Width/Diameter13.25 in / 336.6 mm
Frequency Response (± 3 dB)42 Hz - 22 kHz
Grille PropertiesGalvanized, Magnetic, Micro-Flange, Powder-Coated, White, Paintable, Steel
Magnetically BoostedNo
Nominal Impedance (Ω Ohms)4 Ω
Tweeter Driver1" Soft Dome w/ Unicell Acoustic Treatment
Midrange Driver1.5" Soft Dome w/ Unicell Acoustic Treatment
Woofer Driver5.25" RPF® Flat-Piston Fiberglass & Kevlar Composite Cone w/ NBR Surround
Recommended Power20-200 W
Sensitivity dB @ 2.83V/1M88 dB
