PhaseTech 3-way In-Wall Speaker

PhaseTech CI130 In-Wall Speaker

3-Way In-Wall Speaker with Extruded Aluminum Positive Clamping System. Versatile, high-performance in-wall speaker that can be used to compliment an upper-end home system. The CI130 uses the same woofers and midrange/tweeter assemblies as the Premier Collection series. The tweeter and midrange assembly absorb the horizontal sound waves through Unicell Acoustic treatment to minimize interaction with the mounting wall resulting in amazingly precise imaging and clarity. Additionally, the CI130 employs Phase Tech's patented Positive Clamping System, ensuring accurate control of low end performance and a clear reproduction of the sound into the listening space. 3.75 inch mounting depth allows this speaker to be mounted in shared walls. The CI130 is featured in the EMEA and Global Award Winner installation for CEDIA Best Home Theatre Awards.

Owner's Manual

About PhaseTech
More Information
ColorWhite
UPC644216205202
ManufacturerPhase Technology
Manufacturer's CategoryCI Custom Install Series
Depth3.5 in / 88.9 mm
Height23.5 in / 596.9 mm
Width/Diameter14 in / 355.6 mm
Shipping Weight34.45 lbs / 15.63 kg
Carton Height9 in / 228.6 mm
Carton Length27.5 in / 698.5 mm
Carton Width18.5 in / 469.9 mm
CertificationsCCC, CE, RoHS
Included AccessoriesGrille, Hole Template, Mounting Assembly
Optional AccessoriesRough-In Bracket (RB15)
Source InputsGold Plated Binding Posts
Cutout Depth3.75 in / 95.3 mm
Cutout Width/Diameter13 in / 330.2 mm
Frequency Response (± 3 dB)36 Hz - 22 kHz
Grille PropertiesGalvanized, Magnetic, Micro-Flange, Powder-Coated, White, Paintable, Steel
Max SPL @ 1M120 dB
Nominal Impedance (Ω Ohms)4 Ω
Tweeter Driver1" Soft Dome w/ Unicell Acoustic Treatment
Midrange Driver1.5" Soft Dome w/ Unicell Acoustic Treatment
Woofer Driver6.5" RPF® Flat-Piston Fiberglass & Kevlar Composite Cone w/ NBR Surround
Power for Max SPL250 W
Recommended Power20-250 W
Sensitivity dB @ 2.83V/1M88 dB
